Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: FCTEL
  • Model Number: FC-OV16
  • Wavelength: 850nm/1310nm/1550nm
  • Product name: 16 lines telephone transceiver
  • mode: single mode ,multi mode
  • fiber: 1 core fiber , 2 core fiber
  • Optical Connector: FC SC LC
  • telelphone: 16 POTS , FXO/FXS ,RJ45
  • Transmission Distance: 2km 20km 40km 60km 80km 100km 120km
  • managed: serial manage , snmp manage
  • addtional function: 4 ports E1 , 4 ports ethernet , data
  • Certification: ISO9001:2008 , CE

Packaging & Delivery

Packaging Details: user's manual
power line
standard export carton package
Delivery Detail: 3days for packet
Product Description
PCM 16 lines telephone , analog audio fiber optical multiplexer




  FC-OV16 optical mutiplexer provides 16 FXO/FXS phone,support 4U rack mount .





High lights



1. Based on proprietary integrated circuit;

2. support FXO voice port FXS ports and port magneto telephone interface; FXO port and docking PBX,FXS port is connected to the user's phone;

3.Voice FXO / FXS access, support caller ID function and reverse polarity billing functions;

4.Support Telephone Number mutual function of each site;

5.Unrepeated transmission distance of up to 2 to 120 km;

6. 4U rack machines can provide plug-in, available SNMP network management;

7.Multiple power mode options: AC220V, DC-48V / DC24V, etc;

8. Telephone interface with lightning protection, lightning reached 17626.5 (IEC61000-4-5) Short circuit current wave 8 / 20μs,the peak output voltage 6KV open standards;



Technical parameters



Fiber



Multi-mode Fiber



50/125um, 62.5/125um,

Maximum transmission distance: 2KM,62.5/125um  single mode fiber, attenuation (3dbm/km)

Wave Length: 820nm

Transmitting power: -12dBm (Min) ~-9dBm (Max)

Receiver sensitivity: -28dBm (Min)

Link budget: 16dBm



Single-mode Fiber



8/125um, 9/125um

Maximum transmission distance: 120Km

Transmission distance:120KM,9/125um  single mode fiber, attenuation (0.35dbm/km)

Wave Length: 1310nm

Transmitting power: -9dBm (Min) ~-8dBm (Max)

Receiver sensitivity: -27dBm (Min)

Link budget: 18dBm



FXS Phone Interface

Ring voltage: 75V

Ring frequency: 25HZ

Two-line Impedance: 600 Ohm (pick up)

Return loss: 40 dB



FXO Switch Interface

Ring detect voltage: 35V

Ring detection frequency: 17HZ-60HZ

Two-line Impedance: 600 Ohm (pick up)

Return loss: 40 dB



EM 2/4 Line



AD: 0dB

DA: -3.5dB

Two/Four-line Impedance: 600 Ohm

Return loss: 20 dB



Dimension

Product size:    19 inch 1U  483X138X44mm(WXDXH)

Simple packaging:  522X198X82mm(WXDXH)

Piece weight: 2.1KG



Power

Power supply: AC180V ~ 260V;DC –48V;DC +24V

Power consumption: ≤3W





Working environment

Working temperature: -10°C ~ 50°C
Working Humidity:        5%~95 % (no condensation)

Storage temperature:   -40°C ~ 80°C
Storage Humidity:         5%~95 % (no condensation



Network application
